Ultra 144 : The Sprinter 144 Camper Van With a Shower

Titan Vans · Mercedes Sprinter 144"

Build starts at $169,995 · Van included

The Ultra 144 is Titan's Sprinter 144 camper van with a full indoor shower. It packs a hot shower that doubles as a sauna, a 5-gallon cassette toilet and a 22-gallon wheel well water tank into a van short enough to park in town, with a Bi-Slide Aluminum Bed Platform, a two-person couch and a full galley. It is built on the Mercedes-Benz Sprinter 144" high roof, in rear-wheel drive, 4x4 or AWD, with a Victron 200 Ah Li-Ion Battery and a 330 Watt Solar Panel as standard for time off-grid. Every Ultra 144 is hand-built in Boulder, Colorado; it starts at $169,995 with the van included.

Shower

Sprinter 144 Camper Van With a Shower

Fitting a shower into a 144" Sprinter is all about layout. In the Ultra 144, the interior shower (teak floor mat) is an expandable stall for more upper-body room, with stainless steel fixtures and L-Track inside; the furnace has a second vent in it, so it doubles as a drying room or a sauna. Hot water comes from a 4-gallon electric water heater fed by the 22-gallon wheel well water tank, and the 9-gallon gray water system takes the runoff. That leaves room for the 80" x 61" mattress on the Bi-Slide bed and the galley, so you don't trade the kitchen for the bathroom.

Every Sprinter 144 we build also has a rear utility spray-down shower with pressure and temperature controls and a retractable 7-foot hose, for outdoor showers and rinsing gear. The indoor shower is the Ultra's alone.

Layout

Ultra 144 Floor Plan

From front to back: the rear couch and Lagun Table at the front of the living space on the driver's side, with storage built in underneath; the galley opposite, with an induction cooktop, a large sink and faucet, an Isotherm Drawer 85 Fridge that is also reachable from outside the van, and an Avonite countertop; the shower with the cassette toilet inside it; and the Bi-Slide Aluminum Bed Platform across the rear, with garage storage below. One half of the bed slides into the other to free the floor, and the whole frame lifts out for cargo.

Sleeps up to 5 and seats up to 4, depending on the seating and sleeping options you choose.

Ultra 144 Sprinter 144 camper van floor plan with indoor shower, galley, couch and rear Bi-Slide bed
Ultra 144 floor plan — top view: couch and table forward, galley opposite, indoor shower, Bi-Slide bed at the rear

Specifications

Ultra 144 Specs

The base build. Overall length and height come from the Sprinter itself. Every standard feature is listed under Interior and Exterior, and every add-on under Options.
ChassisMercedes Sprinter 144" high roof (van included)
DrivetrainRWD, 4x4 or AWD: your choice of Sprinter
Model year2027
SeatsUp to 4
SleepsUp to 5
BedBi-Slide Aluminum Bed Platform · 80" x 61" Mattress
Shower and toiletInterior Shower (Teak Floor Mat) · 5 Gal. Cassette Toilet · Rear Utility Spray Down Shower
Fresh / gray water22 Gal. Wheel Well Water Tank · 9 Gal. Gray Water System
Hot water4 Gal. Electric Water Heater
KitchenInduction Cooktop · Isotherm Drawer 85 Fridge · Large Sink + Faucet · Avonite Countertop
LoungeRear Couch · Lagun Table
Battery and solarVictron 200 Ah Li-Ion Battery · 330 Watt Solar Panel · Victron Multiplus 3000 Inverter · 150A Alternator Charging (At Idle) · 30A Shore Power Charging
HeatWebasto Furnace + SmarTemp · Complete Thinsulate Insulation · Rooftop Fan
Starting price$169,995 with the van included

Interior

Interior features infographic of the Ultra 144 Sprinter camper van
Interior cutaway

Ultra 144 Interior Includes

Living Area
Electrical
Water
Heating & Cooling

Exterior

An infographic showing the exterior features of the Ultra camper van
Exterior features

Ultra 144 Exterior Includes

Exterior
Windows

Options

Once you select your camper van model, you may add any of the options below for the price shown on the item's right. Select any option to see photos and full details.

Electrical & Connectivity
Heating & Cooling
Interior
Interior Storage
Exterior
Performance

Compare

Compare Our Sprinter 144 Camper Vans

Titan builds three Sprinter 144 camper vans. Choose the Ultra 144 if the indoor shower matters most. The Metis 144 (from $158,395) is the pick for a double murphy bed that stows to open the garage, with the same couch, galley and cassette toilet; the Classic 144 (from $129,395) is the modular build that seats up to 7 and takes its galley as an option. Each price includes the van. Compare every layout on our Sprinter 144 camper vans page.

Questions

Ultra 144 FAQ

Can a Sprinter 144 camper van have a shower?

Yes. The Ultra 144 has an interior shower as standard: an expandable stall for more upper-body room, a teak floor mat, stainless steel fixtures and integrated hot air, so it doubles as a drying room or a sauna. Hot water comes from a 4-gallon electric water heater fed by a 22-gallon wheel well water tank, and the 9-gallon gray water system takes the runoff.

How much water does the Ultra 144 carry?

A 22-gallon wheel well water tank for fresh water, with a water tank heater pad and a 2.9 GPM pump, plus a 4-gallon electric water heater for hot water and a 9-gallon gray water system under the floor. The 5-gallon cassette toilet can be mounted in several places to suit you.

Is the Ultra 144 available with AWD?

Yes. Order your Sprinter 144 with all-wheel drive or 4x4 and the Ultra is built on it as it is: the shower, the Bi-Slide bed and the galley fit an AWD Sprinter without modification. The off-road, wheel and tire, and skid plate packages are among the options on this page. More on 4x4 and AWD Sprinter conversions.

How much does the Ultra 144 cost?

The Ultra 144 starts at $169,995 for the 2027 model year, with the Mercedes-Benz Sprinter 144 van included and the shower, toilet, galley, couch and Bi-Slide bed as standard. Options are priced on top. Design Your Van prices your exact configuration.

How long does an Ultra 144 build take?

Our current lead time is 4–12 weeks from your deposit, depending on model and options. Chassis availability and the build queue move it, so your estimate confirms the date for your build. Want one sooner? Check our Vans for Sale and Used Camper Vans for Sale pages for an Ultra that is ready now.

Ready to build yours?

Visit our shop in Boulder, Colorado (Monday to Friday, 8 am to 5 pm, by appointment) to sit in a finished van, or start building and pricing yours with the Design Your Van button. Want one sooner? See what is ready now among our vans for sale and used camper vans.
